The mobile scanner turns printed labels into instant navigation. Point the camera at a code and FacilityLane opens the right record — no typing, no searching.

​
Supported formats

The scanner reads four code formats:

​
Scan behaviors

What happens after a scan depends on what the code identifies:
  • Asset code — opens the asset detail screen, with its history and open work orders.
  • Inventory code — opens the part detail screen with quantity on hand and stock status. See Barcodes & QR Codes.
  • Location code — opens the location detail screen.
  • Work order template QR — prefills the work order create form from the template, so recurring jobs start with everything filled in.
Mobile scanner aimed at an asset QR label with the asset detail screen opening

Scanning an asset QR label to open its detail screen

​
Use the scanner

1

Open the scanner

Open the scanner from the mobile app and grant camera permission if prompted.
2

Aim at the code

Center the code in the frame. The scanner detects QR, Code128, EAN-13, and UPC-A automatically — no format selection needed.
Mobile scanner screen with a Code128 barcode centered in the scan frame

The scanner frame centered on a part barcode

3

Act on the result

The matching detail screen opens automatically — or, for a work order template QR, the prefilled create form appears for review and saving.

​
Torch toggle

Scanning in a dark plant room or storeroom? Tap the torch toggle on the scanner screen to turn on the phone’s flashlight while scanning.
Mobile scanner with the torch enabled while scanning a label in low light

The torch toggle illuminating a label in a dark storeroom

Combine template QRs with recurring jobs: post a template QR at the equipment, and any technician can scan it to start a correctly prefilled work order on the spot.
Scanned records open from the offline cache too, so the scanner keeps working without connectivity. See Offline Mode.
