FacilityLane generates a unique QR code for every asset. Attach printed codes to your physical equipment so technicians can pull up the right asset — with its history, procedures, and meters — in one scan, instead of searching by name or tag number.

​
Where to find an asset’s QR code

Every asset detail page displays the asset’s QR code. Open Assets, select an asset, and locate the QR code on the detail page.
Asset detail page with the generated QR code displayed alongside asset details

An asset detail page displaying the asset's QR code

1

Open the asset's QR code

From the asset detail page, open the QR code view. Barcode identification is also supported for equipment already labeled with barcodes.
2

Print the label

Print the code at a size that scans reliably — at least 2.5 cm (1 inch) square for close-range scanning, larger for equipment scanned from a distance.
Print preview showing an asset QR code label with the asset number and name

The print view for an asset QR code label

3

Attach it to the equipment

Place the label somewhere flat, clean, and visible. Avoid curved surfaces, areas that get hot or oily, and spots that will be blocked when panels are closed.
4

Test the scan

Scan the label with the mobile QR scanner to confirm it opens the correct asset before moving to the next one.
Use durable label stock (laminated or polyester labels) for industrial environments. Paper labels fade and peel quickly near heat, moisture, or chemicals.

​
Scan a code with the mobile app

Open the FacilityLane mobile app and tap the QR Scanner. Point the camera at the asset’s code. From the scan you can:
  • Open the asset — view details, status, maintenance history, meters, and attachments.
  • Create a work order — start a new work order with the asset and its location already prefilled, so reporting an issue takes seconds.
Mobile app camera view scanning a QR code attached to a pump

Scanning an asset QR code with the FacilityLane mobile app

Mobile work order form with the asset and location fields prefilled after a QR scan

A new work order prefilled with the scanned asset

Scanning works with both QR codes generated by FacilityLane and existing barcodes recorded against the asset. NFC identification is also supported for tagged equipment.

​
Common questions

Nothing changes for the label. The QR code points to the asset record, not its name or location, so scans keep working after edits.
Yes. Scanning a code and creating a prefilled work order is the fastest way for anyone to report a problem against the right equipment. See Work Orders for how requests are routed.
No. FacilityLane generates a QR code automatically when an asset is created, including assets added via CSV import.
